Transformer data in the Triangle Area

27. Jan. 2023



This dataset contains IoT data every second from 10/0,4 kV transformers and 0,4 kV sub-stations in the TREFOR electricity grid

Geographical location: Triangle Region of Denmark

Author: Center Denmark (https://www.centerdenmark.com/)

Data source: TREFOR El-net (https://www.trefor.dk/elnet/)

Number of transformer stations and sub-stations: 17

Data sensitivy: Raw



Click to request access to the dataset



Notes:

  • Date and time format for the datasets follows the ISO 8601 standard.
  • A validation rule contains a formula or expression that evaluates the data in one or more fields and returns a value of true or false
Transformer data in the Triangle Area

General information



Name

TransformersTriangle

Unique Key

Device Name

Time Column timestamp
Resolution PT1S
Update Frequency PT1H
Dataset Published
Data From 2021-09-06





Timestamp



Name timestamp
Description A date and time are shown in Epoch Unix Time, UTC.
Comment Timestamp column is representing the date and time in the Epoch Unix Time format - i.e. number of seconds elapsed since January 1st, 1970 at midnight.
Data Type Timestamp
Unit
Example 1643760001
Validation Rules



Values



Name rms_voltage
Description Value for RMS voltage.
Comment
Data Type decimal
Unit mV
Example 234282
Validation Rules



Name current_crestfactor
Description Ratio of peak values to effective values of current.
Comment
Data Type decimal
Unit
Example 1.981
Validation Rules



Name current_peak
Description Peak values of current.
Comment
Data Type decimal
Unit mA
Example 38199
Validation Rules



Name current_rms
Description Rms values of current.
Comment
Data Type decimal
Unit mA
Example 16750
Validation Rules



Name active_energy
Description Value for active energy.
Comment
Data Type decimal
Unit mA
Example 53881695222
Validation Rules



Name total_harmonic_distortion
Description The total harmonic distortions in the system.
Comment
Data Type float
Unit decimal
Example 77.5
Validation Rules





Name total_interharmonic_distortion
Description The total interharmonic distortions in the system.
Comment
Data Type decimal
Unit percent
Example 77.5
Validation Rules





Name harmonic_values
Description
Comment
Data Type

integer,

decimal

Unit

Hz,

Percent

Example

[50, 250, 350, 150, 0, 12, 550, 33],

[35.19, 10.85, 8.21, 4.4, 2.64, 2.35, 1.76, 1.17]

Validation Rules





Name active_power
Description Value for active power.
Comment
Data Type decimal
Unit W
Example 3474
Validation Rules





Name power_factor
Description Value for true power factor, the relation between active and reactive power.
Comment
Data Type decimal
Unit
Example 0.903
Validation Rules
