Electricity consumption and production in Western Jutland

27. jan. 2023



This dataset contains electricity consumption (and production) per quarter-hour per electricity meter from RAH El-net area in the Western Region of Jutland.

Geographical location: Western Region of Jutland

Author: Center Denmark (https://www.centerdenmark.com/)

Data source: RAH Net (https://rah.dk/elnettet/)

Number of unique meter ID: > 53.000

Data sensitivy: Raw



Click to request access to the dataset



Notes:

  • Date and time format for the datasets follows the ISO 8601 standard.
  • A validation rule contains a formula or expression that evaluates the data in one or more fields and returns a value of true or false



Electricity consumption and production in Western Jutland

General information



Name

ElectricityConsumptionWesternJutland

Unique Key

installation_id, meter_id

Time Column timestamp
Resolution PT15M
Update Frequency P1D
Dataset Published
Data From 2021-01-06



Timestamp



Name timestamp
Description A date and time are shown in UTC.
Comment Timestamp column is representing the date and time in ISO 8601 format: YYYY-MM-DDTHH:MM:SS.
Data Type Timestamp
Unit
Example 2021-12-01T00:00:00
Validation Rule Always represented in full quarter-hours, i.e., minutes are either 00, 15, 30 or 45.



Product component



Name product_component
Description Value to identifity if it is active-, or reactive power consumption and production.
Comment The Product Component column is a categorical value. The Product Component column has a cardinality of 4 and contains the following categories: 1, 2, 3, 4 (active power consumption, active power production, reactive power consumption, reactive power production).
Data Type integer
Unit
Example 1
Validation Rule  ∈ {1, 2, 3, 4}



Value



Name value
Description Electricity meter measurement values.
Comment Measurement units are based on the Product Component column.
Data Type decimal
Unit

Measurement units are based on the Product Component column:



  • 1 is active power consumption (kWh)
  • 2 is active power production (kWh)
  • 3 is reactive power consumption (kVARh)
  • 4 is reactive power production (kVARh)
Example 0.31
Validation Rule



Installation ID



Name installation_id
Description The installation number follows the installation address
Comment
Data Type string
Unit
Example 1254421
Validation Rule



Meter ID



Name meter_id
Description The meter number identifies individual meters
Comment
Data Type string
Unit
Example 61529547
Validation Rule
