District Heating consumption in the Triangle Area

27. Jan. 2023



This dataset contains hourly district heating consumption data per meter from Fredericia Fjernvarme supply area in Triangle Region Denmark.

Geographical location: Triangle Region of Denmark

Author: Center Denmark (https://www.centerdenmark.com/)

Data source: Fredericia Fjernvarme (https://www.fredericiafjernvarme.dk)

Number of unique meter ID: > 10.000

Data sensitivy: Raw



Click to request access to the dataset



Notes:

  • Date and time format for the datasets follows the ISO 8601 standard.
  • A validation rule contains a formula or expression that evaluates the data in one or more fields and returns a value of true or false



District Heating consumption in the Triangle Area

General information



Name

DistrictHeatingConsumptionTriangleRegion

Unique Key

meter_id

Time Column timestamp
Resolution PT1H
Update Frequency P1D
Dataset Published
Data From 2021-06-16



Timestamp



Name timestamp
Description A date and time are shown in UTC time zone.
Comment Timestamp column is representing the date and time in ISO 8601 format: YYYY-MM-DDTHH:MM:SS.
Data Type timestamp
Unit
Example 2021-12-01T00:00:00
Validation Rule Always represented in full quarter-hours, i.e., minutes are either 00, 15, 30 or 45.



Values



Name forward_temperature
Description The forward temperature of the district heating meter water supply.
Comment
Data Type decimal
Unit Degree Celsius
Example 65.7
Validation Rule



Name return_temperature
Description The return temperature of the district heating meter water supply.
Comment
Data Type decimal
Unit Degree Celsius
Example 40.6
Validation Rule



Name heating_counter_position
Description The Heating Counter Position of the district heating water supply.
Comment To calculate hourly heating consumption, one must subtract the value at the previous timestamp.
Data Type decimal
Unit kWh
Example 38614
Validation Rule



Name flow_rate
Description The flow rate of the district heating water supply.
Comment
Data Type decimal
Unit l/h
Example 16.0
Validation Rule



Name volume_counter_position
Description The Volume Counter Position of the district heating meter water supply.
Comment
Data Type decimal
Unit m3
Example 1776.327
Validation Rule



Meter ID



Name meter_id
Description The meter ID identifies individual meters.
Comment
Data Type string
Unit
Example 65857515
Validation Rule
